GRSC300
GRSC300
GRSC300
GRSC300

GRSC300

GradeScape 300 Bluetooth

Clear convex lens, for uplighting. A complete family of in-grade lighting solutions for a variety of lighting applications. Combines a rugged brass lid with a non-corrosive polymer housing for long life.

Specifications

Lead Wire Length: 60” 16AWG wire lead.

Housing: Non-corrosive polymer.

Lid: Cast brass, attached with 5 color-matched stainless steel screws.

Socket: Spring-loaded ceramic bi-pin MR16, with dual contacts and lamp clips.

Category: Tags: , , , , Brand:
Architectural & Commercial Lighting | US Pole Lighting

Need help?

+1 (661) 233-2000

Architectural & Commercial Lighting | US Pole Lighting

Email us

info@usaltg.com

Architectural & Commercial Lighting | US Pole Lighting

Office hours

7AM - 5PM

GRSC300 – GradeScape 300 Spec Sheet
Watts
  • 4W
  • 5W
  • 6W
Lumen Output
  • 250L
  • 310L
  • 400L
Color Temp - CCT
  • 29K 2900K
Beam Spread
  • 15º
  • 45º
  • 60º
Dimensions
  • Lid Exposed Diameter - 4.87"
  • Buried Fixture Depth - 4.75"
  • Lid Thickness - 0.5"
